22X58 Fuse Link 500V 63A

The 22x58mm 500V 63A Cylindrical Fuse Link is engineered for comprehensive overload and short-circuit protection in low-voltage industrial distribution systems, motor control centers (MCC), and switchgears. Operating under the gG/gL utilization category for full-range line protection, this fuse link combined with a high-strength ceramic body and precision-engineered element delivers exceptional current-limiting performance and an ultra-high breaking capacity up to 120kA.

Dual-Element Precise Melting Grid: The internal fuse element is made of 99.99% pure silver ribbons with precisely calibrated M-effect (Meidinger effect) solder dots. This configuration ensures accurate time-current characteristics, low power dissipation, and prevents false aging under continuous 63A industrial loads.
Reinforced Alumina Ceramic Body: Utilizing premium C795 ceramic material with a tensile strength of 220 MPa or higher, providing superior thermal shock resistance to withstand the extreme localized pressures generated during a 120kA short-circuit fault interruption.
Controlled Grain-Size Quartz Sand: Filled with high-purity crystalline quartz sand (99.7% SiO2 or higher), chemically washed and oven-dried. Automatic vibration compacting ensures zero air pockets, enabling rapid arc extinction within milliseconds and preventing external case shattering.
Low-Loss Nickel-Plated End Caps: Heavy-duty T2 copper end caps with 5um nickel plating provide excellent electrical conductivity and corrosion resistance. Contact resistance is maintained at less than 0.15 mOhm, ensuring temperature rise remains well below the 65K limit specified by IEC 60269.

We deliver industrial-grade customized manufacturing to support global electrical brands, panel builders, and component distributors:

Time-Current Curve Adjustment: Tailored pre-arcing and clearing I2t values to fulfill specific motor-starting (aM category) or semiconductor protection requirements.
Private Labeling & Serialization: High-definition laser marking for client brand logos, custom part numbers, barcodes, and batch traceability codes directly on the ceramic body.
Terminal Configurations: Custom modifications including striker pins (for micro-switch fault signaling) or extended bolt-on tags for direct busbar mounting.

Established in 1988, Zhejiang Chifeng Electric Co., Ltd. is a premier manufacturer dedicated to pioneering fuse technology and delivering high-reliability circuit safety solutions globally.

Decades of Industry Expertise:
Backed by over 35 years of specialized fuse manufacturing experience, trusted by 1,200+ clients worldwide.

Robust Technical Barriers:
Armed with 48 authorized patents (including core invention patents) and 159 qualification certificates, supported by a 65% automation rate in production.

Global Compliance & Certifications:
Formally ISO9001 certified. All products fully comply with IEC 60269 and GB 13539 standards, and hold prestigious international safety marks including CCC, CE, CB, TÜV Rheinland, and UL.

End-to-End Capability:
Operating from a 16,000 m² state-of-the-art facility, we house an in-house R&D center, a dedicated testing lab, and high-precision breaking capacity test systems.

Direct-from-Manufacturer Advantage:
Factory-direct sales model minimizes intermediary markups, ensuring top-tier quality with optimal cost efficiency.

Inner Packaging: 10 pcs per industrial box / 100 pcs per inner master package.
Standard Export Carton: 600 pcs per heavy-duty double-wall corrugated master carton. (Dimensions: 440mm x 260mm x 210mm, Gross Weight: Approx. 33.0 kg).
Palletization & Protection: All air/sea freight shipments are palletized on non-fumigation ISPM-15 plastic or wooden pallets, securely shrink-wrapped with reinforced plastic edge protectors.
Commercial Trade Terms: FOB, CIF, CFR, DDP, EXW.
Production Lead Time: 10-15 working days for standard 63A specifications for orders up to 50,000 pcs. Free samples are available for qualified B2B laboratory validation.
